Objective AI Report
Disclaimer: I am Medbidding AI. I am an unbiased AI robot. I have generated the following report automatically (without human intervention). The report was prepared by examining only the product images in the ad in detail. The report may contain errors. Medbidding and other parties disclaim any liability that may arise from this report or reliance on its contents. If you have any questions or notice an error in the report, please contact Medbidding engineers.
Report date: 26.02.2026
Siemens AXIOM Iconos R200 Fluoroscopy System and Workstation Analysis Report
Device Detection and Identification
The examined images belong to a remotely controlled, conventional fluoroscopy/radiography system that performs diagnostic medical imaging, and its associated control station. The system consists of a motorized patient table, tube stand, vertical chest stand (bucky), mobile monitor trolley, and a workstation including the main control console.
Brand and Model Information
As a result of a detailed visual inspection of the system’s various components, the following brand and model information has been confirmed:
- Fluoroscopy Device (Gantry/Table): The label on the device body clearly shows the SIEMENS logo and the model designation AXIOM Iconos R200.
- Imaging System (PC Unit): The front panel of the processor unit under the control desk features the vertical inscription FLUOROSPOT Compact and the SIEMENS logo.
- Peripherals (Keyboard and Mouse): The keyboard used at the workstation bears the FUJITSU brand logo. The mouse is part of the same set, and its brand logo is faded but design-wise it is compatible.
- Fixed Telephone: The telephone visible on the desk is standard office equipment and not part of the imaging system.
Control Station and Interface Analysis
The operator’s desk shown in the last image is the main center that enables remote control of the system. The hardware in this section includes:
- Main Control Console: An integrated panel is present, managing the system’s table, tube angle, and shooting modes, featuring two joysticks (control levers), a liquid crystal information display, and numerous tactile buttons. A prominent red Emergency Stop button for emergencies is located on the panel.
- Operator Monitor: A square-shaped (4:3 or 5:4 ratio) medical monitor with LCD technology is present.
- PC Tower: The Fluorospot Compact computer case, which manages the system’s image processing and archiving (PACS) processes, is located under the desk.
Screen Analysis and Software Data
When analyzing the image on the workstation monitor, the following data has been identified:
- Active Image: The screen displays a barium swallow study (fluoroscopic image) of the stomach and esophagus in invert contrast (black and white) mode.
- Date Information: The date 21-01-2023 is visible as the examination or acquisition date in the patient data strip at the top right corner of the screen.
- Patient and Institution Information: The patient name “CAVLAK AHMET” appears in the interface. The software interface is Siemens’ standard Syngo-based clinical user interface.
Mechanical and Physical Condition
The general condition of the system has been analyzed based on the visuals as follows:
- Patient Table and Gantry: Although the table surface appears clean, there are minor scuff marks and discoloration on the plastic covers and metal components at the ends, which have occurred over time. No tears were observed in the upholstery.
- Workstation: The keyboard keys show signs of wear (shining) from use. The mouse surface indicates heavy use. The buttons on the console panel are intact, and the joystick caps are in place.
- Plastic Components: The plastic enclosures on the Iconos R200 tower of the device are complete. Yellowing is minimal, retaining its original “medical white/grey” tone.
Component and Quantity Information
The visuals show a total of 1 (one) main system and its associated sub-units. The breakdown is as follows:
- 1 unit Siemens Axiom Iconos R200 Motorized Patient Table and Tube System
- 1 unit Vertical Bucky Stand (Wall-mounted)
- 1 unit Control Console (Desktop unit with joysticks)
- 1 unit Fluorospot Compact Computer Case
- 1 unit Medical Operator Monitor
- 1 unit Fujitsu Keyboard
- 1 unit Mouse
- 1 unit Mobile Monitor Trolley (With separate monitor and consumables shelves)
Accessory and Consumable Status
The following clinical use materials have been identified on the mobile trolley (transport stand):
- Dermosept: One pump bottle of hand antiseptic or surface disinfectant.
- Glove Boxes: 2 boxes of examination gloves with the RT logo and technical markings (CE, single-use indications).
- Textile: A folded white patient gown or sheet on the shelf.
- Cable Management: Cable conduits are present behind the workstation and at wall connections; no exposed or hazardous dangling cables have been detected.
Current Fault and Risk Analysis
- Fault Indication: No “System Error”, “Out of Order” warning, or physically broken, detached part has been detected in the visuals. The presence of an active image on the screen proves that the system has booted up and can acquire images.
- Cosmetic Wear: Minor paint chips caused by impacts on the lower metal chassis coatings and corners of the table are normal, but no signs of rust are prominent in the photographs. The device is installed in an operational clinical room.
Areas of Use
The Siemens AXIOM Iconos R200 is a multi-purpose R/F (Radiography/Fluoroscopy) system designed for gastrointestinal examinations (stomach, intestines), urogenital radiology, skeletal system radiography, venography, and non-interventional fluoroscopic procedures. It is used in hospital radiology units.
Authenticity Status
The logos, typographic characters, color codes (Siemens-specific blue details), and console keypad layout on the product are fully compliant with manufacturer standards. The device is a 100% original Siemens configuration.
